With this article and some others that will follow later we would like to share available knowledge in the PCB design and manufacturing field.
Following some articles related to HDI PCBs we would like to describe the three related more common build-up structures.
HDI PCB types
The design designation system of this standard recognizes industry approved design types used in the manufacture of HDI printed boards. The designations determine the HDI design type by defining the number and location of HDI layers that may or may not be combined with a substrate.
Type I, Standard build-up for HDI
This construction describes an HDI in which there are both blind vias and through vias used for interconnection. Type I constructions describe the fabrication of a single blind via layer on either one or both sides of an PCB substrate core.
The PCB substrate is typically manufactured using conventional PCB techniques and laser via hole technology. The substrate can have as few as one circuit layer or may be as complex as any number of inner layers.
Type II, Sequential build-up 1+N+1
Tipe II is characterized by buried vias in the core and may have through vias through the outer layers. Type II constructions describe an HDI board in which there are plated microvias, plated buried vias and may have PTHs used for surface-to-surface interconnection.
Microvias on layer 1 and layer n grant the connection to conductors on layer 2 and layer n-1, making the connection with the core. Type II constructions can also have PTH to connect layer 1 directly to layer n.
Struttura Tipo III, build-up sequenziale X+N+X
Type III constructions describe an HDI in which there are plated microvias, paste/resin filled holes and through vias used for interconnection. Type III constructions are distinguished by having at least two microvia layers on at least one side of a substrate core. The substrate core is usually manufactured using conventional PCB techniques, may be rigid or flexible, and have as few as one or as many as any number of layers with buried vias.
Where space is minimal and if expressly requested, stacked vias - stacked blind holes - must be used - while where conditions allow it, staggered vias - non-overlapping blind holes on several levels - can be used. Staggered vias are less critical, so preferable, for manufacturing than stacked vias.
For more details, call us +39 059 269711 or send an e-mail sales@cistelaier.com
Following some articles related to HDI PCBs we would like to describe the three related more common build-up structures.
HDI PCB types
The design designation system of this standard recognizes industry approved design types used in the manufacture of HDI printed boards. The designations determine the HDI design type by defining the number and location of HDI layers that may or may not be combined with a substrate.
Type I, Standard build-up for HDI
This construction describes an HDI in which there are both blind vias and through vias used for interconnection. Type I constructions describe the fabrication of a single blind via layer on either one or both sides of an PCB substrate core.
The PCB substrate is typically manufactured using conventional PCB techniques and laser via hole technology. The substrate can have as few as one circuit layer or may be as complex as any number of inner layers.
Type II, Sequential build-up 1+N+1
Tipe II is characterized by buried vias in the core and may have through vias through the outer layers. Type II constructions describe an HDI board in which there are plated microvias, plated buried vias and may have PTHs used for surface-to-surface interconnection.
Microvias on layer 1 and layer n grant the connection to conductors on layer 2 and layer n-1, making the connection with the core. Type II constructions can also have PTH to connect layer 1 directly to layer n.
Struttura Tipo III, build-up sequenziale X+N+X
Type III constructions describe an HDI in which there are plated microvias, paste/resin filled holes and through vias used for interconnection. Type III constructions are distinguished by having at least two microvia layers on at least one side of a substrate core. The substrate core is usually manufactured using conventional PCB techniques, may be rigid or flexible, and have as few as one or as many as any number of layers with buried vias.
Where space is minimal and if expressly requested, stacked vias - stacked blind holes - must be used - while where conditions allow it, staggered vias - non-overlapping blind holes on several levels - can be used. Staggered vias are less critical, so preferable, for manufacturing than stacked vias.
For more details, call us +39 059 269711 or send an e-mail sales@cistelaier.com
Vis mere
Vis mindre
In PCB market,
HDI technology required the adoption of
new technical skills, new machineries and the implementation of the related production processes including that of f
illing the through holes and laser holes, necessary for the realization of" filled and capped vias”, technique also known as "plating over filled vias” well described by the IPC 4761 standard as Type VII filling.
The capped vias technology with hole filling with resin aims to increase the density of the interconnections in printed circuit boards by using the space occupied by through holes as SMD assembly points. This technique consists in filling the holes after plating them, with copper thicknesses on the walls, normally >25µm, and, in any case, defined with the customer.
The resins adopted for "filled and capped vias” have specific insulation properties and dimensional variation with temperatures, they are treated with heat for the relative polymerization and consequent hardening, and, subsequently, are first planarized and then covered with a layer of copper with a thickness of at least 15µm.
This technique can be applied for the realization of different types of printed circuits and with multiple application variants which for this reason are in strong expansion:
- pads used for µBGA, "ball on via technology" and SMD assembly: "Via in Pad Assembly Technology"
- pads used as test points, "Via in Pad Test Technology”
- heat dissipation pads under the cases of the components for "heat management”
- SBU - sequential build up" construction with laser stacked holes on buried holes treated as capped vias
The fundamental operations for filling the holes with resin are carried out in two distinct phases: in the first, the holes are filled with variable pressure and vacuum to allow perfect filling of the holes without the risk of gaps in the resin, while, in the second phase, a surface cleaning of the panel is performed to eliminate the excess resin, facilitating its subsequent planarization.
Whatever the final technology chosen, after complete polymerization, the resin is removed by a mechanical brushing action, called planarization, which can be performed with specific machines that work with cup brushes or with horizontal brushing machines.
The target is to remove the excess resin and create a uniform surface: this operation is a prerequisite for the subsequent over-plating of the filled vias with copper to allow ideal soldering of electronic components. (inserisci disegno).
The knowledge of "capped vias" technology is fundamental today to create compliant pcbs to market and regulations standards required, especially relating to the growing HDI technology demand.
The capped vias technology with hole filling with resin aims to increase the density of the interconnections in printed circuit boards by using the space occupied by through holes as SMD assembly points. This technique consists in filling the holes after plating them, with copper thicknesses on the walls, normally >25µm, and, in any case, defined with the customer.
The resins adopted for "filled and capped vias” have specific insulation properties and dimensional variation with temperatures, they are treated with heat for the relative polymerization and consequent hardening, and, subsequently, are first planarized and then covered with a layer of copper with a thickness of at least 15µm.
This technique can be applied for the realization of different types of printed circuits and with multiple application variants which for this reason are in strong expansion:
- pads used for µBGA, "ball on via technology" and SMD assembly: "Via in Pad Assembly Technology"
- pads used as test points, "Via in Pad Test Technology”
- heat dissipation pads under the cases of the components for "heat management”
- SBU - sequential build up" construction with laser stacked holes on buried holes treated as capped vias
The fundamental operations for filling the holes with resin are carried out in two distinct phases: in the first, the holes are filled with variable pressure and vacuum to allow perfect filling of the holes without the risk of gaps in the resin, while, in the second phase, a surface cleaning of the panel is performed to eliminate the excess resin, facilitating its subsequent planarization.
Whatever the final technology chosen, after complete polymerization, the resin is removed by a mechanical brushing action, called planarization, which can be performed with specific machines that work with cup brushes or with horizontal brushing machines.
The target is to remove the excess resin and create a uniform surface: this operation is a prerequisite for the subsequent over-plating of the filled vias with copper to allow ideal soldering of electronic components. (inserisci disegno).
The knowledge of "capped vias" technology is fundamental today to create compliant pcbs to market and regulations standards required, especially relating to the growing HDI technology demand.
Vis mere
Vis mindre
Stå for haveredskaber, der er nødvendige i enhver havebutik, industriel. Skovlstanden vil perfekt supplere udstillingerne i butikken, i house and garden sektionen. Stabil konstruktion lavet af pulverlakeret metal.
Vis mere
Vis mindre
Metal reol til drikkevarer med 4 etager til hængende flasker. bøjler, der er placeret i Coca-Cola-drikkestativet, gør det nemt at fjerne flasker. Denne løsning giver dig mulighed for at gemme en større mængde af produktet og gøre det endnu mere tilgængeligt for kunderne på salgsstedet.
Vis mere
Vis mindre
Torun vodka stand refererer til en flaske fra 1920'erne, blev designet og fremstillet for at øge synligheden af den stilfulde flaske og understrege den unikke eksponering på salgsstedet. Solide hylder gør det muligt at opbevare 70 flasker og belyse dem med attraktive produktpræsentationer. På den oprindelige måde blev mærket præsenteret, hvilket øgede dets anerkendelse på markedet.
Vis mere
Vis mindre
Peber sæt af to sofaborde, metal pulverlakeret konstruktion, bordplade med møbelplade. Sofaborde er indrettet i minimalistisk stil, ideel til moderne interiør. Peber sofabord sæt tager ikke meget plads, kan du skubbe et mindre bord under den anden eller sat op med to separate
Vis mere
Vis mindre
feb 25 2021
Andet
HDI technology for high-performance printed circuit boards
Dato: 25. februar 2021 16:08
The global electronics market has been pushing for years towards increasing
miniaturization.
This trend is imposed by the market demand for increasingly portable devices, therefore of low weight, and capable of integrating many functions: the real challenge is to reduce the size of the devices, miniaturizing them, and, at the same time, to increase their performance.
The target can be reached basically by working on the structure of the printed circuit board by increasing the density of the components on the surface and the number of connections between the layers that make it up: this need has therefore led to the birth and diffusion of " HDI - High Density Interconnection" structures.
All circuits with pitches’ density per surface with values greater than 20 pitches/cm² greater than traditional printed circuit boards (PCBs) are defined as high interconnection density PCBs (HDI). This therefore results in smaller size for design parameters such as tracks less than 100 ?m/4mils wide, laser holes with a diameter less than 150 ?m/6mils and pitches with a diameter less than 400 ?m/16mils.
keep reading
This trend is imposed by the market demand for increasingly portable devices, therefore of low weight, and capable of integrating many functions: the real challenge is to reduce the size of the devices, miniaturizing them, and, at the same time, to increase their performance.
The target can be reached basically by working on the structure of the printed circuit board by increasing the density of the components on the surface and the number of connections between the layers that make it up: this need has therefore led to the birth and diffusion of " HDI - High Density Interconnection" structures.
